WILDEN 38 mm 1.5 inch Pro-Flo® SHIFT Series Clamped Plastic AODD Pump 04-13297 PS4/PPAPP/ZWS/WF/PTV/0504

04-13297 PS4/PPAPP/ZWS/WF/PTV/0504 When Jim Wilden first added a plastic pump series to his product portfolio, he designed it with what he knew best: a clamped pump. Incorporating the same benefits as a clamped metal pump, these plastic versions offer a simple, rugged design that is ideally suited for chemical applications.

PDF
Product Description:
AIR INLET

  • 3/4" FNPT

LIQUID INLET

  • 38 mm (1-1/2")

LIQUID DISCHARGE

  • 38 mm (1-1/2")

CONNECTION TYPE

  • DIN/ANSI (Flanged)

MAX SUCTION LIFT CAPABILITY

  • Rubber – 5.9 m (19.5') Dry, 8.3 (27.2') Wet

  • EZ-Install TPE – 6.2 m (20.4') Dry, 8.3 m (27.2') Wet

  • Full-Stroke PTFE – 6.1 m (19.9') Dry, 8.3 m (27.2') Wet


Performance and Specifications

Dimensions

Dim-PS4-38mm

Note: Dimensions vary by material and connection. For additional information, please refer to the PS4 Plastic Manual.

Flow Curve – EZ-Install TPE-Fitted

Flo-PS4-38mm

Note: Additional performance curves can be found in the PS4 Plastic Manual.

AIR INLET

  • 3/4" FNPT

LIQUID INLET

  • 38 mm (1-1/2")

LIQUID DISCHARGE

  • 38 mm (1-1/2")

CONNECTION TYPE

  • DIN/ANSI (Flanged)

MAX FLOW RATE

  • Rubber – 379 lpm (100 gpm)

  • EZ-Install TPE – 378 lpm (100 gpm)

  • Full-Stroke PTFE – 368 lpm (98 gpm)

MAX PRESSURE

  • 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

  • 4.8 mm (3/16")

MAX SUCTION LIFT CAPABILITY

  • Rubber – 5.9 m (19.5') Dry, 8.3 (27.2') Wet

  • EZ-Install TPE – 6.2 m (20.4') Dry, 8.3 m (27.2') Wet

  • Full-Stroke PTFE – 6.1 m (19.9') Dry, 8.3 m (27.2') Wet

DISPLACEMENT PER STROKE *

  • Rubber –1.0 L (0.26 gal)

  • EZ-Install TPE – 1.0 L (0.26 gal)

  • Full-Stroke PTFE – 1.0 L (0.26 gal)

    • * 1 cycle = 2 strokes


Other models are recommended：

NumberingDescriptionNumberingDescription
04-13975PS4/AAAAA/ZGS/BN/BN/032704-13095XPS4/SSAAA/TSS/TF/STF/0070
04-13436PS4/AAAAR/ZGS/BN/BN/005004-12918XPS4/SSAAA/TWS/TF/STF
04-13437PS4/AAAAR/ZGS/BN/BN/005104-12919XPS4/SSAAA/TWS/TF/STF/0014
04-13438PS4/AAAAR/ZPS/NE/NE/005004-13490XPS4/SSAAA/TWS/TF/STF/0070
04-13439PS4/AAAAR/ZPS/NE/NE/005104-13984XPS4/SSAAA/VTS/VT/STF
04-13684PS4/AAAPP/BNS/BN/BN04-13470XPS4/SSAAA/VTS/VT/STF/0014
04-13308PS4/KKAPP/TWS/TF/KTV04-14048XPS4/SSAAA/VTS/VT/VT
04-13309PS4/KKAPP/TWS/TF/KTV/050404-14068XPS4/SSAAA/VTS/VT/VT/0014
04-13312PS4/KKAPP/ZWS/WF/KTV04-12922XPS4/SSAAA/ZGS/BN/BN
04-13313PS4/KKAPP/ZWS/WF/KTV/050404-12923XPS4/SSAAA/ZGS/BN/BN/0014
04-13785PS4/KKSPP/TWS/TF/KTV04-14220XPS4/SSAAA/ZPS/PU/PU/0014
04-13782PS4/PPAPP/BNS/BN/PBN04-13812XPS4/SSAAA/ZSS/FS/FS/0014
04-13531PS4/PPAPP/BNS/BN/PBN/050404-12975XPS4/SSAAA/ZSS/FS/FS/0070
04-13292PS4/PPAPP/TWS/TF/PTV04-12924XPS4/SSAAA/ZWS/WF/WF
04-13293PS4/PPAPP/TWS/TF/PTV/050404-12925XPS4/SSAAA/ZWS/WF/WF/0014
04-13298PS4/PPAPP/VTS/VT/PTV04-13393XPS4/SSNNN/FWS/FW/FE/0770
04-13294PS4/PPAPP/ZGS/BN/PBN04-13487XPS4/SSNNN/FWS/FW/FW/0070
04-13296PS4/PPAPP/ZWS/WF/PTV04-13403XPS4/SSNNN/TSS/TF/TF/0771
04-13297PS4/PPAPP/ZWS/WF/PTV/050404-13832XPS4/SSNNN/TWS/TF/STF
04-13827PS4/PPCPP/TWS/TF/PTV/050204-13362XPS4/SSNNN/TWS/TF/STF/0070
04-13383PS4/PPSPP/TWS/TF/PTV04-13395XPS4/SSNNN/TWS/TF/TF/0770
04-13775PS4/SSSPP/EPS/EP/EP04-13794XPS4/SSNNN/ZSS/FS/FS/0070
04-13250PS4/SSSPP/TWS/TF/STF04-13397XPS4/SSNNN/ZSS/FS/TF/0770
04-13251PS4/SSSPP/TWS/TF/STF/001404-13335XPS4/SSSAA/TWS/TF/STF/0070
04-13669PS4/SSSPP/TWS/TF/STF/007004-13019XPS4/SSSAA/VTS/VT/VT
04-13256PS4/SSSPP/VTS/VT/VT04-13736XPS4/SSSSS/FBS/FB/TF/0770
04-13257PS4/SSSPP/VTS/VT/VT/001404-13618XPS4/SSSSS/FES/FS/FS/0070
04-13254PS4/SSSPP/ZWS/WF/WF04-13394XPS4/SSSSS/FWS/FW/FE/0770
04-13255PS4/SSSPP/ZWS/WF/WF/001404-13741XPS4/SSSSS/TSS/TF/STF/0070
04-13442PS4/WMAAR/ZGS/BN/BN/005004-13404XPS4/SSSSS/TSS/TF/TF/0771
04-13443PS4/WMAAR/ZGS/BN/BN/005104-13208XPS4/SSSSS/TWS/TF/STF
04-13444PS4/WMAAR/ZPS/NE/NE/005004-13209XPS4/SSSSS/TWS/TF/STF/0014
04-13445PS4/WMAAR/ZPS/NE/NE/005104-13449XPS4/SSSSS/TWS/TF/STF/0070
04-13447PS4/WMAAR/ZWS/EP/EP/005104-13396XPS4/SSSSS/TWS/TF/TF/0770
04-12898XPS4/AAAAA/BNS/BN/BN04-14017XPS4/SSSSS/TWS/TF/TF/0771
04-12899XPS4/AAAAA/BNS/BN/BN/001404-13214XPS4/SSSSS/VTS/VT/VT
04-13681XPS4/AAAAA/BNS/BN/BN/004404-13215XPS4/SSSSS/VTS/VT/VT/0014
04-13781XPS4/AAAAA/BNS/BN/BN/032004-13641XPS4/SSSSS/ZSS/FS/FS/0070
04-13412XPS4/AAAAA/EPS/EP/EP04-13398XPS4/SSSSS/ZSS/FS/TF/0770
04-14061XPS4/AAAAA/EPS/EP/EP/001404-13212XPS4/SSSSS/ZWS/WF/WF
04-12900XPS4/AAAAA/FWS/WF/WF04-13213XPS4/SSSSS/ZWS/WF/WF/0014
04-12901XPS4/AAAAA/FWS/WF/WF/001404-13807XPS4/SZAAA/FSL/FS/FS/0070
04-12902XPS4/AAAAA/NES/NE/NE04-13325XPS4/SZAAA/FWL/FW/FW/0070
04-12903XPS4/AAAAA/NES/NE/NE/001404-13809XPS4/SZNNN/FSL/FS/FE/0770
04-13086XPS4/AAAAA/NES/NE/NE/004404-14281XPS4/SZNNN/FSL/TF/FE/0770
04-14024XPS4/AAAAA/TSS/TF/ATF/001404-13391XPS4/SZNNN/FWL/FW/FE/0770
04-12904XPS4/AAAAA/TWS/TF/ATF04-13399XPS4/SZNNN/FWL/FW/FE/0771
04-12905XPS4/AAAAA/TWS/TF/ATF/001404-13468XPS4/SZNNN/FWL/FW/FW/0070
04-13426XPS4/AAAAA/VTS/VT/VT04-13483XPS4/SZNNN/FWL/TF/TF/0771
04-13429XPS4/AAAAA/VTS/VT/VT/001404-13407XPS4/SZNNN/LEL/TF/TF/0770
04-12908XPS4/AAAAA/ZGS/BN/BN04-13409XPS4/SZNNN/LEL/TF/TF/0771
04-12909XPS4/AAAAA/ZGS/BN/BN/001404-13392XPS4/SZSSS/FWL/FW/FE/0770
04-13514XPS4/AAAAA/ZPS/PU/PU04-13400XPS4/SZSSS/FWL/FW/FE/0771
04-13997XPS4/AAAAA/ZPS/PU/PU/001404-13408XPS4/SZSSS/LEL/TF/TF/0770
04-13987XPS4/AAAAA/ZSS/BN/BN/003004-13410XPS4/SZSSS/LEL/TF/TF/0771
04-14131XPS4/AAAAA/ZSS/FS/FS04-13780XPS4/WMAAA/BNS/BN/BN
04-12910XPS4/AAAAA/ZWS/WF/WF04-14083XPS4/WMAAA/BNS/BN/BN/0014
04-12911XPS4/AAAAA/ZWS/WF/WF/001404-13406XPS4/WMAAA/EPS/EP/EP
04-14161XPS4/AZAAA/WWL/TF/ATF04-13530XPS4/WMAAA/EPS/EP/EP/0014
04-14207XPS4/AZAAA/WWL/WF/WF04-12976XPS4/WMAAA/NES/NE/NE
04-12912XPS4/SSAAA/BNS/BN/BN04-13014XPS4/WMAAA/NES/NE/NE/0014
04-12913XPS4/SSAAA/BNS/BN/BN/001404-13110XPS4/WMAAA/TWS/TF/MTF
04-13380XPS4/SSAAA/EPS/EP/EP04-13101XPS4/WMAAA/TWS/TF/MTF/0014
04-13381XPS4/SSAAA/EPS/EP/EP/001404-14004XPS4/WMAAA/TWS/TF/STF
04-13374XPS4/SSAAA/FES/TF/STF/007004-13623XPS4/WMAAA/TWS/VT/VT/0044
04-13434XPS4/SSAAA/FWS/FW/FW/007004-13417XPS4/WMAAA/XBS/BN/BN/0014
04-14037XPS4/SSAAA/FWS/TF/FW/007004-13648XPS4/WMAAA/ZGS/BN/BN
04-12914XPS4/SSAAA/FWS/WF/WF04-13662XPS4/WMAAA/ZPS/PU/PU
04-12915XPS4/SSAAA/FWS/WF/WF/001404-13418XPS4/WMAAA/ZPS/PU/PU/0014
04-12916XPS4/SSAAA/NES/NE/NE04-13333XPS4/WMAAA/ZWS/WF/WF
04-12917XPS4/SSAAA/NES/NE/NE/001404-13330XPS4/WMAAA/ZWS/WF/WF/0014
04-14101XPS4/SSAAA/TSS/TF/STF04-13705XPS4/WMAAR/ZGS/BN/BN/0053


MAX FLOW RATE

  • Rubber – 379 lpm (100 gpm)

  • EZ-Install TPE – 378 lpm (100 gpm)

  • Full-Stroke PTFE – 368 lpm (98 gpm)

MAX PRESSURE

  • 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

  • 4.8 mm (3/16")

DISPLACEMENT PER STROKE *

  • Rubber –1.0 L (0.26 gal)

  • EZ-Install TPE – 1.0 L (0.26 gal)

  • Full-Stroke PTFE – 1.0 L (0.26 gal)

    • * 1 cycle = 2 strokes
