3/4" FNPT
51 mm (2")
51 mm (2")
NPT/BSPT (Threaded)
Rubber – 7.2 m (23.8') Dry, 9.0 m (29.5') Wet
EZ-Install TPE – 6.9 m (22.7') Dry, 9.0 m (29.5') Wet
Full-Stroke PTFE – 6.3 m (20.7') Dry, 8.6 m (28.4') Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the PS8 Metal Manual.
Note: Additional performance curves can be found in the PS8 Metal Manual.
3/4" FNPT
51 mm (2")
51 mm (2")
NPT/BSPT (Threaded)
Rubber – 700 lpm (185 gpm)
EZ-Install TPE – 719 lpm (190 gpm)
Full-Stroke PTFE – 723 lpm (191 gpm)
8.6 bar (125 psi)
6.4 bar (1/4")
Rubber – 7.2 m (23.8') Dry, 9.0 m (29.5') Wet
EZ-Install TPE – 6.9 m (22.7') Dry, 9.0 m (29.5') Wet
Full-Stroke PTFE – 6.3 m (20.7') Dry, 8.6 m (28.4') Wet
Rubber – 2.6 L (0.69 gal)
EZ-Install TPE – 2.6 L (0.69 gal)
PTFE Full-Stroke – 2.4 L (0.64 gal)
| Material | Ship Wt |
|---|---|
| Aluminum | 35 kg (78 lb) |
| Stainless Steel | 53 kg (117 lb) |
| Ductile Iron | 49 kg (109 lb) |
| Description | Material |
|---|---|
| Center Section | Aluminum, Nickel-Plated Aluminum, Stainless Steel, Polypropylene |
| Air Valve | Aluminum, Nickel-Plated Aluminum, Anodized Aluminum, Stainless Steel, Polypropylene |
| Air Chamber | Aluminum, Nickel-Plated Aluminum, Stainless Steel |
Rubber – 700 lpm (185 gpm)
EZ-Install TPE – 719 lpm (190 gpm)
Full-Stroke PTFE – 723 lpm (191 gpm)
8.6 bar (125 psi)
6.4 mm (1/4")
Rubber – 2.6 L (0.69 gal)
EZ-Install TPE – 2.6 L (0.69 gal)
Full-Stroke PTFE – 2.4 L (0.64 gal)
