WILDEN Pro-flo Series 1-1/2" Bolt-On Metal Air Operated Diaphragm Pump

Hot selling models
P420/AAAPP/EPS/EP/EP
P420/AAAPP/TNU/TF/ATF
P420/AAAPP/TWS/TF/ATF
P420/AAAPP/TWS/TF/ATF/0014
P420/AAAPP/ZWS/WF/WF
P420/AAAPP/ZWS/WF/WF/0014
P420/SSAPP/TWS/TF/STF
P420/SSAPP/TWS/TF/STF/0014
P420/SSAPP/ZWS/WF/WF
P420/SSAPP/ZWS/WF/WF/0014
P430/AAAPP/BNS/BN/BN
P430/AAAPP/BNS/BN/BN/0504
P430/AAAPP/NES/NE/NE
P430/AAAPP/TNU/TF/ATF
P430/AAAPP/TWS/TF/ATF
P430/AAAPP/TWS/TF/ATF/0504
P430/AAAPP/ZWS/WF/WF
P430/AAAPP/ZWS/WF/WF/0504
P430/SSAPP/BNS/BN/BN/0504
P430/SSAPP/EPS

PDF
Product Description:
AIR INLET

  • 1/2" FNPT

LIQUID INLET

  • 38 mm (1-1/2")

LIQUID DISCHARGE

  • 38 mm (1-1/2")

CONNECTION TYPE

  • NPT/BSPT (Threaded)

  • DIN/ANSI (Flanged)

MAX SUCTION LIFT CAPABILITY

  • Rubber – 5.5 m (18.2') Dry, 9.0 m (29.5') Wet

  • EZ-Install TPE – 4.8 m (15.9') Dry, 9.0 m (29.5') Wet

  • Full-Stroke PTFE – 5.2 m (17.0') Dry, 9.0 m (29.5') Wet

  • Reduced-Stroke PTFE – 2.8 m (9.1') Dry, 9.0 m (29.5') Wet


Performance and Specifications

Dimensions

Dim-P420-P430-38mm1.5in-BMP

Note: Dimensions vary by material and connection. For additional information, please refer to the P420/P430 Metal Manual.

Flow Curve – EZ-Install TPE-Fitted

Flo-P420-P430-38mm1.5in-BMP

Note: Additional performance curves can be found in the P420/P430 Metal Manual.

AIR INLET

  • 1/2" FNPT

LIQUID INLET

  • 38 mm (1-1/2")

LIQUID DISCHARGE

  • 38 mm (1-1/2")

CONNECTION TYPE

  • NPT/BSPT (Threaded)

  • DIN/ANSI (Flanged)

MAX FLOW RATE

  • Rubber – 492 lpm (130 gpm)

  • EZ-Install TPE – 492 lpm (130 gpm)

  • Full-Stroke PTFE – 473 lpm (125 gpm)

  • Reduced-Stroke PTFE – 341 lpm (90 gpm)

MAX PRESSURE

  • 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

  • 6.4 mm (1/4")

MAX SUCTION LIFT CAPABILITY

  • Rubber – 5.5 m (18.2') Dry, 9.0 m (29.5') Wet

  • EZ-Install TPE – 4.8 m (15.9') Dry, 9.0 m (29.5') Wet

  • Full-Stroke PTFE – 5.2 m (17.0') Dry, 9.0 m (29.5') Wet

  • Reduced-Stroke PTFE – 2.8 m (15.9') Dry, 9.0 m (29.5') Wet

DISPLACEMENT PER STROKE *

  • Rubber – 1.2 L (0.32 gal)

  • TPE – 1.2 L (0.32 gal)

  • Full-Stroke PTFE – 1.1 L (0.28 gal)

  • Reduced-Stroke PTFE – 0.53 L (0.14 gal)

    • * 1 cycle = 2 strokes


MAX FLOW RATE

  • Rubber – 492 lpm (130 gpm)

  • EZ-Install TPE – 492 lpm (130 gpm)

  • Full-Stroke PTFE – 473 lpm (125 gpm)

  • Reduced-Stroke PTFE – 341 lpm (90 gpm)

MAX PRESSURE

  • 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

  • 6.4 mm (1/4”)

DISPLACEMENT PER STROKE *

  • Rubber – 1.2 L (0.32 gal)

  • TPE – 1.2 L (0.32 gal)

  • Full-Stroke PTFE – 1.1 L (0.28 gal)

  • Reduced-Stroke PTFE – 0.53 L (0.14 gal)

    • * 1 cycle = 2 strokes
