Item: 01-10073 Model: P1/AAPPP/FSS/FS/AFS Series: Pro-Flo Wetted material: Aluminum Diaphragm / check balls: Hytrel® / Hytrel® Fluid connections: 1/2-inch NPT, center swivel Maximum flow: 15.4 US gpm (58.3 L/min) Maximum pressure: 125 psig (8.6 bar) Air repair kit: 01-9985-20 Wet-end repair kit: 01-9804-56
WILDEN / PRO-FLO SERIES
A compact air-operated double-diaphragm pump with an aluminum wetted housing, Hytrel® diaphragms and Hytrel® check balls. The Pro-Flo air distribution system is paired with a clamped assembly and NPT fluid connections. Center-swivel ports simplify inlet and discharge alignment.
Complete model
P1/AAPPP/FSS/FS/AFS
FLUID CONNECTION
1/2-inch NPT
MAXIMUM FLOW
≈ 58.3 L/min
MAXIMUM PRESSURE
125 psig
| Brand / item number | WILDEN / 01-10073 |
|---|---|
| Pump series | Pro-Flo |
| Nominal fluid port size | 1/2 in (0.5 in) |
| Drive / construction | Pneumatic / clamped |
| Wetted housing | Aluminum |
| Diaphragms | Hytrel® (FSS), traditional full-stroke design |
| Check balls / valve seats | Hytrel® / aluminum |
| Connection standard | NPT threaded |
| Inlet / discharge orientation | Center swivel / center swivel |
| Maximum flow | 15.4 US gpm (approximately 58.3 L/min) |
|---|---|
| Maximum pressure | 125 psig (approximately 8.6 bar) |
| Maximum solids diameter | 0.06 in (approximately 1.5 mm) |
| Self-priming | Yes |
| Listed shipping weight | Approximately 5.90 kg (13 lb) |
Maximum flow and maximum pressure are separate ratings. Select the duty point from the performance curve for the available air supply and actual installation.
| Air-side material | Polypropylene |
|---|---|
| Outer pistons | Aluminum |
| Wetted O-rings / gaskets | Hytrel® |
| Check-valve type | Ball valve |
| Muffler | Plastic |
P1 metal / TPE performance curve. Click the chart to open the full-size image.
P1 metal suction curve. Read the TPE diaphragm trace for the Hytrel® configuration.
Example duty point
5 US gpm (18.9 L/min) at 40 psig discharge pressure uses approximately 60 psig air supply and 3.5 scfm air consumption in the manufacturer’s example.
AIR REPAIR KIT
For 1/2-inch Pro-Flo P-series pumps with a plastic air valve. Applicable P1 and P100 configurations; services the air distribution side.
WET-END REPAIR KIT
For 1/2-inch Original clamped metal pumps with Hytrel® (FSS) diaphragms. Matches the wetted-end service configuration of 01-10073.
Repair kits are ordered separately. Match the complete pump code and installed elastomers when selecting service parts.
Quote 01-10073 and P1/AAPPP/FSS/FS/AFS, together with quantity, fluid, temperature, flow and discharge pressure. For service kits, include the kit number and a clear pump nameplate photo.
