Item: 02-12026 Model: XPX220/AAAAA/BNS/BN/ABN/0687 Series: Pro-Flo X Wetted material: Aluminum Diaphragm material: Buna-N Nominal fluid port size: 1-inch Construction: Bolted
WILDEN / PRO-FLO X SERIES
This 1-inch Pro-Flo X air-operated double-diaphragm pump uses aluminum wetted housing and Buna-N diaphragms. Its bolted construction is identified by the complete ordering code below.
Complete model
XPX220/AAAAA/BNS/BN/ABN/0687
FLUID PORT SIZE
1-inch
| Brand / item number | WILDEN / 02-12026 |
|---|---|
| Pump series | Pro-Flo X |
| Nominal fluid port size | 1 in |
| Construction | Bolted |
| Wetted housing | Aluminum |
| Diaphragm material | Buna-N |
| Check ball material | Buna-N |
| Valve seat material | Aluminum |
| Outer pistons | Aluminum |
|---|---|
| Wetted O-rings / gaskets | Buna-N |
| Special option code | 0687 |
AIR REPAIR KIT
Air distribution service kit matched to this 1-inch Pro-Flo X XPX220 configuration. Confirm the complete pump code when ordering.
WET-END REPAIR KIT
Wetted-end service kit matched to this 1-inch bolted pump with Buna-N diaphragms. Match the installed elastomers and full ordering code.
Repair kits are ordered separately. Include the complete pump code and kit number in your enquiry.
Quote 02-12026 and XPX220/AAAAA/BNS/BN/ABN/0687, together with quantity, fluid, operating temperature, required flow and discharge pressure. For replacement parts, include the component number and a clear pump nameplate photo.
