Item: 02-13578 Model: XP200/FKJJJ/TNU/TF/KTV Series: Pro-Flo Wetted material: Conductive PVDF Diaphragm material: PTFE Nominal fluid port size: 1-inch Construction: Bolted
WILDEN / PRO-FLO SERIES
This 1-inch Pro-Flo air-operated double-diaphragm pump uses conductive pvdf wetted housing and PTFE diaphragms. Its bolted construction is identified by the complete ordering code below.
Complete model
XP200/FKJJJ/TNU/TF/KTV
FLUID PORT SIZE
1-inch
| Brand / item number | WILDEN / 02-13578 |
|---|---|
| Pump series | Pro-Flo |
| Nominal fluid port size | 1 in |
| Construction | Bolted |
| Wetted housing | Conductive PVDF |
| Diaphragm material | PTFE |
| Check ball material | PTFE |
| Valve seat material | PVDF |
| Outer pistons | PVDF |
|---|---|
| Wetted O-rings / gaskets | PTFE-encapsulated FKM |
WET-END REPAIR KIT
Wetted-end service kit matched to this 1-inch bolted pump with PTFE diaphragms. Match the installed elastomers and full ordering code.
Repair kits are ordered separately. Include the complete pump code and kit number in your enquiry.
Quote 02-13578 and XP200/FKJJJ/TNU/TF/KTV, together with quantity, fluid, operating temperature, required flow and discharge pressure. For replacement parts, include the component number and a clear pump nameplate photo.
