Item: 02-13588 Model: XP200/JKJJJ/EPS/EP/PTV Series: Pro-Flo Wetted material: Conductive polypropylene Diaphragm material: EPDM Nominal fluid port size: 1-inch Construction: Bolted
WILDEN / PRO-FLO SERIES
This 1-inch Pro-Flo air-operated double-diaphragm pump uses conductive polypropylene wetted housing and EPDM diaphragms. Its bolted construction is identified by the complete ordering code below.
Complete model
XP200/JKJJJ/EPS/EP/PTV
FLUID PORT SIZE
1-inch
| Brand / item number | WILDEN / 02-13588 |
|---|---|
| Pump series | Pro-Flo |
| Nominal fluid port size | 1 in |
| Construction | Bolted |
| Wetted housing | Conductive polypropylene |
| Diaphragm material | EPDM |
| Check ball material | EPDM |
| Valve seat material | Polypropylene |
| Outer pistons | PVDF |
|---|---|
| Wetted O-rings / gaskets | PTFE-encapsulated FKM |
Quote 02-13588 and XP200/JKJJJ/EPS/EP/PTV, together with quantity, fluid, operating temperature, required flow and discharge pressure. For replacement parts, include the component number and a clear pump nameplate photo.
