38 mm (1-1/2") Pro-Flo® SHIFT Series Clamped Metal AODD Pump

Dimensions

Note: Dimensions vary by material and connection. For additional information, please refer to the P100 Plastic Manual.

Flow Curve – TPE-Fitted

Note: Additional performance curves can be found in the P100 Plastic Manual.

AIR INLET

• 1/4" FNPT

LIQUID INLET

• 13 mm (1/2")

LIQUID DISCHARGE

• 13 mm (1/2")

CONNECTION TYPE

• NPT/BSPT (Threaded)

MAX FLOW RATE

• Rubber – 56 lpm (14.8 gpm)

• TPE – 58.7 lpm (15.5 gpm)

• PTFE – 57 lpm (15 gpm)

MAX PRESSURE

• 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

• 1.6 mm (1/16")

MAX SUCTION LIFT CAPABILITY

• Rubber – 5.2 m (17.0') Dry, 8.7 m (28.4') Wet

• TPE – 5.2 m (17.0') Dry, 5.5 m (18.0') Wet

• PTFE – 4.5 m (14.7') Dry, 9.3 (30.6') Wet

DISPLACEMENT PER STROKE *

• Rubber – 0.10 L (0.027 gal)

• TPE – 0.11 L (0.029 gal)

• PTFE – 0.10 L (0.027 gal)

* 1 cycle = 2 strokes

Wetted Housings

Non-Wetted Housings
