Hot selling models P2/KKPPP/TNU/TF/KTV/0400 P2/KKPPP/TWS/TF/KTV/0400 P2/KKPPP/WFS/TF/KTV/0400 P2/KKPPP/WFS/WF/KTV/0400 P2/PKPPP/BNS/BN/KBN/0400 P2/PKPPP/EPS/EP/PTV/0400 P2/PKPPP/NES/NE/PBN/0400 P2/PKPPP/TEU/TF/PTV/0404 P2/PKPPP/TNU/TF/PTV/0400 P2/PKPPP/TWS/TF/PTV/0400 P2/PKPPP/TWS/TF/PTV/0404 P2/PKPPP/VTS/VT/PTV/0400 P2/PKPPP/WFS/WF/PTV/0400 P2/PKPPP/WFS/WF/PTV/0404 P2/PKPPP/WFS/WF/PWF/0400
1/4" FNPT
25 mm (1")
25 mm (1")
DIN/ANSI (Flanged)
Rubber – 5.5 m (18.0') Dry, 8.8 m (29.0') Wet
TPE – 5.5 m (18.0') Dry, 8.8 m (29.0') Wet
Full-Stroke PTFE – 4.1 m (13.6') Dry, 8.6 m (28.4') Wet
Reduced-Stroke PTFE – 3.4 m (11') Dry, 8.8 m (29') Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the P2 Plastic Manual.
Note: Additional performance curves can be found in the P2 Plastic Manual.
1/4" FNPT
25 mm (1")
25 mm (1")
DIN/ANSI (Flanged)
Rubber – 140 lpm (37 gpm)
TPE – 140 lpm (37 gpm)
Full-Stroke PTFE – 139 lpm (36.8 gpm)
Reduced-Stroke PTFE – 132 lpm (35 gpm)
8.6 bar (125 psi)
3.2 mm (1/8'')
Rubber – 5.5 m (18.0') Dry, 8.8 m (29.0') Wet
TPE – 5.5 m (18.0') Dry, 8.8 m (29.0') Wet
Full-Stroke PTFE – 4.1 m (13.6') Dry, 8.6 m (28.4') Wet
Reduced-Stroke PTFE – 3.4 m (11') Dry, 8.8 m (29') Wet
Rubber – 0.31 L (0.08 gal)
TPE – 0.39 L (0.10 gal)
Full-Stroke PTFE – 0.6 L (0.15 gal)
Reduced-Stroke PTFE – 0.23 L (0.06 gal)
| Material | Ship Wt |
|---|---|
| Polypropylene | 8 kg (18 lb) |
| PVDF | 10 kg (23 lb) |
| Description | Material |
|---|---|
| Center Section | Polypropylene, Acetal |
| Air Valve | Polypropylene, Acetal |
Rubber – 140 lpm (37 gpm)
TPE – 140 lpm (37 gpm)
Full-Stroke PTFE – 121 lpm (32 gpm)
Reduced-Stroke PTFE – 132 lpm (35 gpm)
8.6 bar (125 psi)
3.2 mm (1/8'')
Rubber – 0.31 L (0.08 gal)
TPE – 0.39 L (0.10 gal)
Full-Stroke PTFE – 0.23 L (0.06 gal)
Reduced-Stroke PTFE – 0.23 L (0.06 gal)
