WILDEN Pro-flo Series P2 Aluminum, Stainless Steel Diaphragm Pump WILDEN Pro-flo Series P2 Aluminum, Stainless Steel Diaphragm Pump

WILDEN Pro-flo Series P2 Aluminum, Stainless Steel Diaphragm Pump

Hot selling models
P2/AAPPP/BNS/BN/ABN/2000
P2/AAPPP/BNS/BN/ABN/2014
P2/AAPPP/NES/NE/ABN/2014
P2/AAPPP/TSS/TF/ATF/2014
P2/AAPPP/TSU/TF/ATF/2000
P2/AAPPP/TSU/TF/ATF/2014
P2/AAPPP/TWS/TF/ATF/2000
P2/AAPPP/TWS/TF/STF/2491
P2/AAPPP/WFS/WF/AWF/2000
P2/SSPPP/EPS/EP/SEP/2014
P2/SSPPP/FES/TF/STF/0070
P2/SSPPP/FSS/FS/SFS/0070
P2/SSPPP/FSS/FS/SFS/2070
P2/SSPPP/FSS/TF/SFS/0070
P2/SSPPP/NES/NE/SBN/2014
P2/SSPPP/TEU/TF/STF/0070
P2/SSPPP/TNU/TF/STF/2000
P2/SSPPP/TNU/TF/STF/2014
P2/SSPPP/TSU

PDF
Product Description:
AIR INLET

  • 1/4" FNPT

LIQUID INLET

  • 25 mm (1")

LIQUID DISCHARGE

  • 19 mm (3/4")

CONNECTION TYPE

  • NPT/BSPT (Threaded)

MAX SUCTION LIFT CAPABILITY

  • Rubber – 5.2 m (17.0') Dry, 9.0 m (29.5') Wet

  • TPE – 7.6 m (25.0') Dry, 9.0 m (29.5') Wet

  • Full-Stroke PTFE – 4.7 m (15.3') Dry, 9.0 m (29.5') Wet

  • Reduced-Stroke PTFE – 2.8 m (9.1') Dry, 9.0 m (29.5') Wet



Performance and Specifications

Dimensions

Dim-P2-25mm1in-CMP

Note: Dimensions vary by material and connection. For additional information, please refer to the P2 Metal Manual.

Flow Curve – TPE-Fitted

Flo-P2-25mm1in-CMP

Note: Additional performance curves can be found in the P2 Metal Manual.

AIR INLET

  • 1/4" FNPT

LIQUID INLET

  • 25 mm (1")

LIQUID DISCHARGE

  • 19 mm (3/4")

CONNECTION TYPE

  • NPT/BSPT (Threaded)

MAX FLOW RATE

  • Rubber – 172 lpm (45.5 gpm)

  • TPE – 171 lpm (45.2 gpm)

  • Full-Stroke PTFE – 167 lpm (44.1 gpm)

  • Reduced-Stroke PTFE – 155 lpm (41 gpm)

MAX PRESSURE

  • 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

  • 3.2 mm (1/8'')

MAX SUCTION LIFT CAPABILITY

  • Rubber – 5.2 m (17.0') Dry, 9.0 m (29.5') Wet

  • TPE – 7.6 m (25.0') Dry, 9.0 m (29.5') Wet

  • Full-Stroke PTFE – 4.7 m (15.3') Dry, 9.0 m (29.5') Wet

  • Reduced-Stroke PTFE – 2.8 m (9.1') Dry, 9.0 m (29.5') Wet

DISPLACEMENT PER STROKE *

  • Rubber – 0.3 L (0.08 gal)

  • TPE – 0.3 L (0.08 gal)

  • Full-Stroke PTFE – 0.3 L (0.08 gal)

  • Reduced-Stroke PTFE – 0.3 L (0.08 gal)

    • * 1 cycle = 2 strokes

Wetted Housings

MaterialShip Weight
Aluminum9 kg (20 lb)
Stainless Steel17 kg (37 lb)

Non-Wetted Housings

DescriptionMaterial
Center SectionPolypropylene, Acetal
Air ValvePolypropylene, Acetal


MAX FLOW RATE

  • Rubber – 172 lpm (45.5 gpm)

  • TPE – 171 lpm (45.2 gpm)

  • Full-Stroke PTFE – 167 lpm (44.1 gpm)

  • Reduced-Stroke PTFE – 155 lpm (41 gpm)

MAX PRESSURE

  • 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

  • 3.2 mm (1/8'')

DISPLACEMENT PER STROKE *

  • Rubber – 0.3 L (0.08 gal)

  • TPE – 0.3 L (0.08 gal)

  • Full-Stroke PTFE – 0.3 L (0.08 gal)

  • Reduced-Stroke PTFE – 0.3 L (0.08 gal)

    • * 1 cycle = 2 strokes
